FEATURES
- High Quality Toroidal Transformer
- Separate ground for each rail.
- Ultra low ripple noise.
- No humming or buzz noise for 50Hz and peak load.
- Newly designed the Circuit that do not use any ICs. It is truly Analog design.
- Quantum Resonance technology "that provides a subtle field that makes all electromechanical components resonate in unison to improve coherence and timing."
- There are 4 zone and each zone are separated.
- USB Isolator for audiophile grade systems. PCM support up to 24Bit/96kHz. DSD support to DSD64.
- New in-house Audio Grade foot cone.
Output Voltage and Current
Zone I: 5V/7V/9V/12V, 4A.
Zone II: 12V/15V/19V/24V, 6A.
Zone III: 5V/9V, 2A.
Zone IV: USB 5V, 2A.
USB Isolator
Support low and full speed data rate for 1.5 Mbps and 12 Mbps.
Applications
1. Audiophile grad systems.
2. Machine protection.
3. Measurement devices, test gear.
4. Medical environment.
Ripple Noise
<100uV at full power
<10uV at 60% load
Power Requirment
Standby: 0.5 Watt
Maximum: 500 Watts
Casing
All Aluminum
Dimension (WxDxH)
300x279x66mm
Weight
Net Weight 7KG
Shipping Weight 9KGOutput Voltage and Current
Zone I: 5V/7V/9V/12V, 4A.
Zone II: 12V/15V/19V/24V, 6A.
Zone III: 5V/9V, 2A.
Zone IV: USB 5V, 2A.
USB Isolator
Support low and full speed data rate for 1.5 Mbps and 12 Mbps.
Applications
1. Audiophile grad systems.
2. Machine protection.
3. Measurement devices, test gear.
4. Medical environment.
Ripple Noise
<100uV at full power
<10uV at 60% load
Power Requirment
Standby: 0.5 Watt
Maximum: 500 Watts
Casing
All Aluminum
Dimension (WxDxH)
300x279x66mm
Weight
Net Weight 7KG
Shipping Weight 9KG
